12V 60W TEC1-12706 Heatsink Thermoelectric Cooler Peltier Cooling Plate Module

12V 60W TEC1-12706 Heatsink Thermoelectric Cooler Peltier Cooling Plate Module

  • 12V 60W TEC1-12706 Heatsink Thermoelectric Cooler Peltier Cooling Plate Module
  • 12V 60W TEC1-12706 Heatsink Thermoelectric Cooler Peltier Cooling Plate Module
  • 12V 60W TEC1-12706 Heatsink Thermoelectric Cooler Peltier Cooling Plate Module
12V 60W TEC1-12706 Heatsink Thermoelectric Cooler Peltier Cooling Plate Module
Product Details:
Place of Origin: China
Brand Name: OEM
Model Number: oky3550
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: $1.21-1.55 per piece
Packaging Details: Different anti-static package at optional: 1. Full or partial package according as your requirement. 2. Retailing Box package design according to your requirement ( Order > 2000PCS )
Delivery Time: 3-5 wook days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 1000pcs per day
Contact Now
Detailed Product Description
Chip: TEC1-12706 The External Size: 40 * 40 * 3.75 Mm
Internal Resistance Value: 2.1 ~ 2.4 Ω (23 + / - 1 ℃, Environment Temperature 1 KHZ Ac Test) The Largest Temperature Difference: Delta Tmax (Qc = 0) More Than 67 ℃
Working Current: Imax = 4.3-4.6 A Rated (12 V) Rated Voltage: 12V Starting Current (Vmax: 15 V 5.8 A)
Cooling Power Qcmax: 60-72W Working Conditions:: Temperature Range And 55 ℃ ~ 80 ℃ (high Environmental Temperature Drop Directly Affect The Cooling Efficiency)
High Light:

arduino sensors kit

,

arduino temperature sensor

12V 60W TEC1-12706 Heatsink Thermoelectric Cooler Peltier Cooling Plate Module



Description:

Model: TEC1-12706
Size: 40 x 40 (mm)
Voltage :12V
Umax :15V
Imax :4.3~4.6A
QMax :72W
Power Cord :300mm
Weight :approximately 25g
Fitted with 6-inch insulated leads
Each device is full inspected and tested
These devices must be used in conjunction with a heat sink to avoid burned
Since they consit primarily of semiconductor material sandwiched between ceramic plates and have no moving parts
Get ice cold in minutes or heat to boiling by simply reversing the polarity, used for numerous applications from CPU coolers to alternate power sources, or even for your own custom car drink warmer/cooler



Installation:
Cooling piece is very simple to install and use. Before installation, to find a dry cell, connected to the two leads of the cooler, obviously cold you can feel at one end and the other end of fever, remember that the polarity of the lead and determine a good cooler cold and hot end. If you want to get a bigger system Ling, it is recommended that two cooling mode, with two stack up with the above, a grim absorption following a fever, the experiments prove two refrigeration effect is much better than the single-stage, the condition can choose three, of course, have a large power supply support.



Photos:

12V 60W TEC1-12706 Heatsink Thermoelectric Cooler Peltier Cooling Plate Module 0

12V 60W TEC1-12706 Heatsink Thermoelectric Cooler Peltier Cooling Plate Module 1



FAQ:



1. What is the delivery time?

Normally, 1-5 workdays after payment;

Special requirement orders, delivery time is negotiable.



2.If the products can’t work after receiving it,what should I do?

We will replace new items for you at once, and respect your final decision for wrong goods.



3.If the products don’t meet my demand after I received it,can I return it?

Yes,no problem.

You can return back to us, we will refund your full payment.



Competitive Advantage:



1. Convenient & Friendly Customer Service
2. Low Prices Direct From Factory Suppliers
3. Fast Delivery Around the World.
4. High Quality With Global Standards.
5. 1 Year Factory Warranty
6. Safe Shipping Way and Payment
